Frame
Heyday! Carbon
-
Color
Black Cherry
-
Fork
Kingpin Carbon
-
Headset
Cane Creek 40 Series
-
Seatpost
TranzX YSP18JL, XS–SM: 100mm travel; MD–XL: 130mm travel
-
Stem
Salsa Guide Trail 35.0
-
Grips/bar tape
Salsa File Tread
-
Saddle
WTB Volt Medium
-
Handlebar
Kalloy 35.0mm, XS–SM: 760mm, 0mm rise; MD–XL: 780mm, 15mm rise
-
Rear derailleur
Shimano Deore M6100
-
Cassette
Shimano Deore M6100, 10–51t, 12-speed
-
Chain
Shimano Deore M6100
-
Crankset
Race Face Ride, SH12 direct-mount chainring, 30t
-
Shifter
Shimano Deore M6100-R
-
Brake levers
SRAM Level
-
Brake calipers
SRAM Level
-
Bottom bracket
Race Face, BSA, 24mm spindle, 100mm
-
Rotors
SRAM G2 CleanSweep (6-bolt, 180mm front, 160mm rear)
-
Front wheel
Sun Ringle SRC 15 x 150 mm hub, Mulefüt SL 80 mm rim
-
Rear wheel
Sun Ringle SRC 12 x 197 mm hub, Mulefüt SL 80 mm rim
-
Front tire
45NRTH Dillinger 5, 26 x 4.6", 60TPI, studdable, tubeless-ready
-
Rear tire
45NRTH Dillinger 5, 26 x 4.6", 60TPI, studdable, tubeless-ready
-
Weight (complete bike)
31 lb 9 oz for Medium
-
Geometry measurement basis
A Salsa Kingpin fork which is equivalent to a 100mm RockShox Bluto fork at 25% sag; A 26 x 4.8" tire measuring 759mm in diameter; Standover is measured from ground to top of toptube at forward portion of the kink
-
Design wheel/tire sizes
26 x 4.33" on up to 100mm rim
-
Alternate wheel/tire sizes
26 x 3.8–4.8" on up to 100mm rim; 27.5 x 3.0–4.0"; 29 x 2.3–3.0"
-
Suspension fork length (travel)
511mm (100mm)
-
Rigid fork length
483–486mm
-
Fork offset
50–51mm
-
Rear spacing
197 x 12mm thru-axle
-
Rear axle size
12 x 229L, TP = 1.5, TL = 20
-
Rear brake (rotor)
51mm standard (160–180mm rotors). Must use 160mm rear IS adapter with +20mm post mount adapter for 180mm rotor
-
Front brake (rotor)
74mm post mount (160–180mm)
-
Headset - upper
IS41
-
Headset - lower
IS52
-
Front spacing
150 x 15mm thru-axle
-
Front axle size
15 x 198L, TP = 1.5, TL = 9
-
Crown race
Ø40mm
-
Stem clamp
Ø28.6mm
-
Seatpost
31.6mm
-
Dropper post compatible
Yes, internal
-
Seatpost clamp
35.0mm
-
Front derailleur clamp
High direct-mount (54mm offset) via removable bracket (included)
-
Front derailleur type
Compact 2x top-pull only
-
Derailluer hanger
Fixed Position - ND: FS2357, D: FS2355; / Adjustable - ND: FS2353, D: FS2356
-
Bottom bracket
100mm, threaded
-
Crankset (max ring)
75mm chainline fat bike cranks only 2x: 36/24t max; 1x: 32t max
-
Accessory mounts
2 per frame
-
Bottle mounts
2 per frame
-
Fork mounts
2 Three-Pack bosses per fork
